Solutions for some challenges in Flare On 11
Flare On 11
Challenge 2: checksum
Challenge Overview
The challenge provides us with a PE64 file written in Golang, along with several questions related to the result of a “checksum” calculation.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
| C:\Users\PWN2OWN>"C:\Users\PWN2OWN\FlareOn\2024\checksum.exe"
Check sum: 9418 + 92 = 9510
Good math!!!
------------------------------
Check sum: 9397 + 3991 = 13388
Good math!!!
------------------------------
Check sum: 5380 + 1695 = 7075
Good math!!!
------------------------------
Check sum: 3936 + 7655 = 11591
Good math!!!
------------------------------
Checksum: aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
Maybe it's time to analyze the binary! ;)
|
Challenge Static Analysis
The program contains three non-library functions: main_main, main_a, main_b.
First, randomTimes represents the number of math questions to be generated, with its value randomly chosen in the range [0, 5]. This value is then increased by 3, resulting in a total of 3 to 8 arithmetic questions.
Each question randomly generates two operators, which I renamed to fsRandom and seRandom. The player’s task is to input the correct sum of these two numbers. If all answers are correct, the program proceeds to the next stage.
The program then prompts for a checksum input and verifies its validity using a Golang API.
The input_checksum must be exactly 32 bytes long, where the first 24 bytes are extracted as the buffer. The program uses the XChaCha20-Poly1305 encryption algorithm, which requires a 32-byte key and a 24-byte nonce. Based on this, we can hypothesize that the buffer serves as the nonce in this encryption scheme.
By decoding the encryptedFlagData using the key and the nonce mentioned above, we obtain the decrypted data.
The decrypted data is hashed using SHA-256, then converted to a hexadecimal string and compared with input_checksum. If they match, the function main_a is called and the result is printed to {os_UserCacheDir}\REAL_FLAREON_FLAG.JPG.
Analyzing the main_a function, we can see that its logic is relatively straightforward. The input_checksum is XORed with the string FlareOn2024, then base64-encoded and compared with the string: cQoFRQErX1YAVw1zVQdFUSxfAQNRBXUNAxBSe15QCVRVJ1pQEwd/WFBUAlElCFBFUnlaB1ULByRdBEFdfVtWVA==.
Find flag
1
2
3
4
5
6
| >>> x = b"cQoFRQErX1YAVw1zVQdFUSxfAQNRBXUNAxBSe15QCVRVJ1pQEwd/WFBUAlElCFBFUnlaB1ULByRdBEFdfVtWVA=="
>>> y = b"FlareOn2024"
>>> import base64
>>> xx = base64.b64decode(x)
>>> "".join(chr(xx[i] ^ y[i % len(y)]) for i in range(len(xx)))
'7fd7dd1d0e959f74c133c13abb740b9faa61ab06bd0ecd177645e93b1e3825dd'
|
Finding flag in local app data
Challenge 3: aray
The challenge provides a YARA rule file, and the task is to find an input that satisfies all the conditions defined in the rule.
Clean code
First, clean up the code by replacing all occurrences of and with line breaks (\n) for better readability. At a glance, there are two types of data involved:
with operands: +, -, &, %.
Additionally, there are several comparisons using hash functions like sha256, md5, and crc32 such as:
1
2
3
4
5
6
7
8
9
10
| hash.crc32(8, 2) == 0x61089c5c
hash.crc32(34, 2) == 0x5888fc1b
hash.crc32(63, 2) == 0x66715919
hash.sha256(14, 2) == "403d5f23d149670348b147a15eeb7010914701a7e99aad2e43f90cfa0325c76f"
hash.sha256(56, 2) == "593f2d04aab251f60c9e4b8bbc1e05a34e920980ec08351a18459b2bc7dbf2f6"
hash.md5(0, 2) == "89484b14b36a8d5329426a3d944d2983"
hash.crc32(78, 2) == 0x7cab8d64
hash.md5(76, 2) == "f98ed07a4d5f50f7de1410d905f1477f"
hash.md5(50, 2) == "657dae0913ee12be6fb2a6f687aae1c7"
hash.md5(32, 2) == "738a656e8e8ec272ca17cd51e12f558b"
|
With each chunk being only 2 bytes, it’s easy to brute-force to find values that satisfy these conditions.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
| # Define all hash targets and positions
targets = [
('crc32', 8, 0x61089c5c),
('crc32', 34, 0x5888fc1b),
('crc32', 63, 0x66715919),
('sha256', 14, "403d5f23d149670348b147a15eeb7010914701a7e99aad2e43f90cfa0325c76f"),
('sha256', 56, "593f2d04aab251f60c9e4b8bbc1e05a34e920980ec08351a18459b2bc7dbf2f6"),
('md5', 0, "89484b14b36a8d5329426a3d944d2983"),
('crc32', 78, 0x7cab8d64),
('md5', 76, "f98ed07a4d5f50f7de1410d905f1477f"),
('md5', 50, "657dae0913ee12be6fb2a6f687aae1c7"),
('md5', 32, "738a656e8e8ec272ca17cd51e12f558b"),
]
# Choose charset (printable ASCII)
charset = range(32, 127)
# Brute-force
for hash_type, offset, expected in targets:
# print(f"[*] Brute-forcing {hash_type} at offset {offset}...")
found = False
for c1, c2 in itertools.product(charset, repeat=2):
pair = bytes([c1, c2])
if hash_type == 'crc32':
h = binascii.crc32(pair) & 0xffffffff
if h == expected:
found = True
elif hash_type == 'sha256':
h = hashlib.sha256(pair).hexdigest()
if h == expected:
found = True
elif hash_type == 'md5':
h = hashlib.md5(pair).hexdigest()
if h == expected:
found = True
if found:
s.add(flag[offset] == c1)
s.add(flag[offset + 1] == c2)
break
if not found:
print(f"[-] No match found at offset {offset}")
|
For the remaining conditions, we can easily solve them using Z3.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
| from z3 import *
filesize = 85
flag = [BitVec(f"b{i}", 85 * 8) for i in range(filesize)]
s = Solver()
s.add((filesize ^ flag[11]) != 107 )
s.add((flag[55]) & 128 == 0 )
s.add((flag[58]) + 25 == 122 )
s.add((flag[7]) & 128 == 0 )
s.add((flag[48]) % 12 < 12 )
[...]
if (s.check() == sat):
res = bytearray()
for b in flag:
res.append(s.model()[b].as_long())
print(res)
|
Flag
Full script
1
2
| C:\Users\PWN2OWN\CTF\Flare-On\Flare11\3_aray\aray>python brute.py
bytearray(b'rule flareon { strings: $f = "1RuleADayK33p$Malw4r3Aw4y@flare-on.com" condition: $f }')
|
Challenge 4: FLARE Meme Maker 3000
The challenge provides a mememaker3000.html file containing an obfuscated JavaScript snippet.
Deobfuscate
Deobfuscate using the website https://deobfuscate.relative.im, the resulting source code is quite clear:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
| const a0c = [
'When you find a buffer overflow in legacy code',
'Reverse Engineer',
'When you decompile the obfuscated code and it makes perfect sense',
'Me after a week of reverse engineering',
'When your decompiler crashes',
"It's not a bug, it'a a feature",
"Security 'Expert'",
'AI',
"That's great, but can you hack it?",
'When your code compiles for the first time',
"If it ain't broke, break it",
"Reading someone else's code",
'EDR',
'This is fine',
'FLARE On',
"It's always DNS",
'strings.exe',
"Don't click on that.",
'When you find the perfect 0-day exploit',
'Security through obscurity',
'Instant Coffee',
'H@x0r',
'Malware',
'$1,000,000',
'IDA Pro',
'Security Expert',
],
a0d = {
doge1: [
['75%', '25%'],
['75%', '82%'],
],
boy_friend0: [
['75%', '25%'],
['40%', '60%'],
['70%', '70%'],
],
draw: [['30%', '30%']],
drake: [
['10%', '75%'],
['55%', '75%'],
],
two_buttons: [
['10%', '15%'],
['2%', '60%'],
],
success: [['75%', '50%']],
disaster: [['5%', '50%']],
aliens: [['5%', '50%']],
},
a0e = {
'doge1.png':
'draw.jpg':
'drake.jpg':
'two_buttons.jpg':
'fish.jpg':
'data:binary/red;base64, [...]',
'boy_friend0.jpg':
'success.jpg':
'disaster.jpg':
'aliens.jpg':
}
function a0f() {
document.getElementById('caption1').hidden = true
document.getElementById('caption2').hidden = true
document.getElementById('caption3').hidden = true
const a = document.getElementById('meme-template')
var b = a.value.split('.')[0]
a0d[b].forEach(function (c, d) {
var e = document.getElementById('caption' + (d + 1))
e.hidden = false
e.style.top = a0d[b][d][0]
e.style.left = a0d[b][d][1]
e.textContent = a0c[Math.floor(Math.random() * (a0c.length - 1))]
})
}
a0f()
const a0g = document.getElementById('meme-image'),
a0h = document.getElementById('meme-container'),
a0i = document.getElementById('remake'),
a0j = document.getElementById('meme-template')
a0g.src = a0e[a0j.value]
a0j.addEventListener('change', () => {
a0g.src = a0e[a0j.value]
a0g.alt = a0j.value
a0f()
})
a0i.addEventListener('click', () => {
a0f()
})
function a0k() {
const a = a0g.alt.split('/').pop()
if (a !== Object.keys(a0e)[5]) {
return
}
const b = a0l.textContent,
c = a0m.textContent,
d = a0n.textContent
if (
a0c.indexOf(b) == 14 &&
a0c.indexOf(c) == a0c.length - 1 &&
a0c.indexOf(d) == 22
) {
var e = new Date().getTime()
while (new Date().getTime() < e + 3000) {}
var f = d[3] + 'h' + a[10] + b[2] + a[3] + c[5] + c[c.length - 1] + '5' + a[3] + '4' + a[3] + c[2] + c[4] + c[3] + '3' + d[2] + a[3] + 'j4' + a0c[1][2] + d[4] + '5' + c[2] + d[5] + '1' + c[11] + '7' + a0c[21][1] + b.replace(' ', '-') + a[11] + a0c[4].substring(12, 15)
f = f.toLowerCase()
alert(atob('Q29uZ3JhdHVsYXRpb25zISBIZXJlIHlvdSBnbzog') + f)
}
}
const a0l = document.getElementById('caption1'),
a0m = document.getElementById('caption2'),
a0n = document.getElementById('caption3')
a0l.addEventListener('keyup', () => {
a0k()
})
a0m.addEventListener('keyup', () => {
a0k()
})
a0n.addEventListener('keyup', () => {
a0k()
})
|
Get flag
There is a base64 encoded string with the content Congratulations! Here you go: . From this, we can deduce that the a0k() function contains the flag. There are 2 conditions that need to be bypassed:
First, the meme template must satisfy:
1
2
3
| if (a !== Object.keys(a0e)[5]) {
return
}
|
Second, the text in the boxes must satisfy:
1
2
3
4
5
| if (
a0c.indexOf(b) == 14 &&
a0c.indexOf(c) == a0c.length - 1 &&
a0c.indexOf(d) == 22
)
|
To satisfy the first condition, we just need to declare:
1
| a = Object.keys(a0e)[5]
|
For the second condition, we just need to change the values of the elements right after randomization:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
| function a0f() {
document.getElementById('caption1').hidden = true
document.getElementById('caption2').hidden = true
document.getElementById('caption3').hidden = true
const a = document.getElementById('meme-template')
var b = a.value.split('.')[0]
a0d[b].forEach(function (c, d) {
var e = document.getElementById('caption' + (d + 1))
e.hidden = false
e.style.top = a0d[b][d][0]
e.style.left = a0d[b][d][1]
e.textContent = a0c[Math.floor(Math.random() * (a0c.length - 1))]
})
document.getElementById('caption1').textContent = 'FLARE On'
document.getElementById('caption2').textContent = 'Security Expert'
document.getElementById('caption3').textContent = 'Malware'
}
|
After reloading the page, we get the flag: wh0a_it5_4_cru3l_j4va5cr1p7@flare-on.com.
Challenge 5: sshd
Challenge Information
- Given file: sshd.7z
- Description: Our server in the FLARE Intergalactic HQ has crashed! Now criminals are trying to sell me my own data!!! Do your part, random internet hacker, to help FLARE out and tell us what data they stole! We used the best forensic preservation technique of just copying all the files on the system for you.
7zip archive password: flare
Opinion
In my opinion, this is one of the best challenges in the series. It is related to cases of real-world cybersecurity incidents and mentions a very interesting backdoor that was discovered last year.
Part 1: Overview
The challenge provides a filesystem image.
The description mentions that the server crashed due to something. When an application crashes on Linux, the coredump file is stored at /var/lib/systemd/coredump. There is a coredump file related to the sshd process.
1
2
| ➜ ls ./var/lib/systemd/coredump
sshd.core.93794.0.0.11.1725917676
|
To get a clearer picture of the memory at the time the process crashed, I used GDB for analysis.
1
| ➜ gdb ./usr/sbin/sshd ./var/lib/systemd/coredump/sshd.core.93794.0.0.11.1725917676
|
Looking at the information provided by the bt command, the program crashed due to calling a function at address 0x0000000000000000. The function that caused the crash is at address 0x00007f4a18c8f88f, located in the liblzma.so.5 library.
Observing the memory mapping information using the info proc mappings command, we see that starting from address 0x7f4a18c86000, there are memory regions that have been deleted but contain the faulty code at 0x00007f4a18c8f88f.
Update the base address of the library in IDA PRO to facilitate analysis of the liblzma.so.5 library.
Part 2: Analysis The library
Jumping to the address that caused the crash, the function that caused the error is sub_7F4A18C8F820, with the content renamed as follows:
Normally, dlsym would call the RSA_public_decrypt function by its exact name. However, symbol_name has an extra space at the end. Therefore, dlsym returns NULL, and the code below causes a crash.
What we need to pay attention to is the code at line[20:26]. Thanks to the string expand 32-byte k, we can determine that the encryption algorithm is likely ChaCha20 or Salsa20. Its operation flow can be summarized as follows:
The process involves mapping and copying the encrypted shellcode into a memory region with full RWX permissions. After that, the shellcode is decrypted, executed, and then re-encrypted to avoid detection.
The next task is to decrypt the shellcode.
There are several ways to decrypt the shellcode. You can dump the init_chacha20_block, sus_crypto_fn, from, and encrypted_shellcode functions and use Unicorn or Ghidra + plugin to emulate and analyze.
I choose a different way to save time, though it may be more error-prone. Find the key and nonce and manually decrypt the shellcode.
The v10 function — the one that caused the crash calls the from variable as its second parameter. Therefore, rsi will store the value of the from variable
1
| (v10)(flen, from, to, rsa, padding)
|
From there, it’s easy to determine: key = from + 4 and nonce = from + 0x24 based on the call to init_chacha20_block_sub_7F4A18C8F3F0(v14, (from + 4), (from + 0x24), 0LL).
We see that rsi = from = 0xc5407a48, which matches the backdoor signature check. Continue to decrypt the shellcode with the key and nonce just found.
1
2
3
4
5
6
7
8
9
10
11
12
13
| from Crypto.Cipher import ChaCha20
key = b"\x94\x3d\xf6\x38\xa8\x18\x13\xe2\xde\x63\x18\xa5\x07\xf9\xa0\xba\x2d\xbb\x8a\x7b\xa6\x36\x66\xd0\x8d\x11\xa6\x5e\xc9\x14\xd6\x6f"
nonce = b"\xf2\x36\x83\x9f\x4d\xcd\x71\x1a\x52\x86\x29\x55"
with open("./dumped_bytes.bin", "rb") as f:
encrypted_data = f.read()
cipher = ChaCha20.new(key=key, nonce=nonce)
decrypted_data = cipher.decrypt(encrypted_data)
with open("decrypted_shellcode.bin", "wb") as f:
f.write(decrypted_data)
|
Part 3: Analysis Shellcode
The shellcode is quite short and straightforward. It frequently sets the value of the rax register to call syscalls in the form {push value; pop rax}
To summarize, the shellcode’s operation flow is as follows:
- Create a socket and connect to
10.0.2.15:1337 - Receive 0x20 bytes
key - Receive 12 bytes
nonce - Receive 4 bytes
size_of_file_path_name - Receive
size_of_file_path_name bytes file_path - Open the file
- Read 0x80 bytes from
file_path, store in file_content - Initialize ChaCha20/Salsa algorithm
- Encrypt file_content using the above algorithm
- Send
encrypted_file_content_size to C2 - Send
encrypted_file_content to C2 - Close the file
- Shutdown the connection
Searching for strings in the coredump file, we find a very important path /root/certificate_authority_signing_key.txt. Opening HxD, we can easily see that the values around the path match the operation flow summarized above.
- Green underline:
key - Orange underline:
nonce - Red underline:
size_of_file_path_name
Using IDA PRO, we calculate the offset of path_name relative to file_content.
Returning to decrypting the data, the shellcode used the ChaCha20 algorithm but with a custom sigma expand 32-byte K.
Rewrite the entire ChaCha20 decryption function instead of using the library, and we get the challenge flag.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
| import struct
def rotate(v, c):
return ((v << c) & 0xffffffff) | (v >> (32 - c))
def quarter_round(x, a, b, c, d):
x[a] = (x[a] + x[b]) & 0xffffffff
x[d] ^= x[a]
x[d] = rotate(x[d], 16)
x[c] = (x[c] + x[d]) & 0xffffffff
x[b] ^= x[c]
x[b] = rotate(x[b], 12)
x[a] = (x[a] + x[b]) & 0xffffffff
x[d] ^= x[a]
x[d] = rotate(x[d], 8)
x[c] = (x[c] + x[d]) & 0xffffffff
x[b] ^= x[c]
x[b] = rotate(x[b], 7)
def chacha20_block(key, counter, nonce, sigma):
state = (
list(struct.unpack('<4I', sigma)) +
list(struct.unpack('<8I', key)) +
[counter] +
list(struct.unpack('<3I', nonce))
)
working_state = state[:]
for _ in range(10): # 20 rounds (10 double rounds)
quarter_round(working_state, 0, 4, 8, 12)
quarter_round(working_state, 1, 5, 9, 13)
quarter_round(working_state, 2, 6, 10, 14)
quarter_round(working_state, 3, 7, 11, 15)
quarter_round(working_state, 0, 5, 10, 15)
quarter_round(working_state, 1, 6, 11, 12)
quarter_round(working_state, 2, 7, 8, 13)
quarter_round(working_state, 3, 4, 9, 14)
for i in range(16):
working_state[i] = (working_state[i] + state[i]) & 0xffffffff
return struct.pack('<16I', *working_state)
def chacha20_decrypt(key, nonce, ciphertext, counter=0, sigma=b"expand 32-byte K"):
assert len(key) == 32
assert len(nonce) == 12
assert len(sigma) == 16
plaintext = b""
for block_index in range(0, len(ciphertext), 64):
block = chacha20_block(key, counter, nonce, sigma)
chunk = ciphertext[block_index:block_index + 64]
keystream = block[:len(chunk)]
plaintext += bytes([c ^ k for c, k in zip(chunk, keystream)])
counter += 1
return plaintext
key = b"\x8D\xEC\x91\x12\xEB\x76\x0E\xDA\x7C\x7D\x87\xA4\x43\x27\x1C\x35\xD9\xE0\xCB\x87\x89\x93\xB4\xD9\x04\xAE\xF9\x34\xFA\x21\x66\xD7"
nonce = b"\x11\x11\x11\x11\x11\x11\x11\x11\x11\x11\x11\x11"
encrypted_data = b"\xA9\xF6\x34\x08\x42\x2A\x9E\x1C\x0C\x03\xA8\x08\x94\x70\xBB\x8D\xAA\xDC\x6D\x7B\x24\xFF\x7F\x24\x7C\xDA\x83\x9E\x92\xF7\x07\x1D\x02\x63\x90\x2E\xC1\x58"
custom_sigma = b"expand 32-byte K"
plaintext = chacha20_decrypt(key, nonce, encrypted_data, counter=0, sigma=custom_sigma)
print("Decrypted:", plaintext)
# Decrypted: b'supp1y_cha1n_sund4y@flare-on.com\n\x86Xm\xb4U'
|
Challenge 6: bloke2
